MTW European Trapezium Mill

INPUT SIZE: Up to 50mm PRODUCTION CAPACITY: 3.5-45T/h

MTW European Type Trapezium mill is the newest grinding equipment which enjoys many patented technology and reaches the international advanced level.3.With reliable and advanced technology of Inner automatic Thin-oil lubricating system.First, raw material should be crushed by the jaw crusher to the size specified, and then the crushed stuff is elevated into a...

1.Linkage supercharging device of rollers, stable operation and advanced productivity.
2.Bevel gear overall drive, less energy loss, higher efficiency.
3.With reliable and advanced technology of Inner automatic Thin-oil lubricating system.
4.Arc air channel, less air flow loss, better material fluidity.
5.Special design of rollers and ring, replaceable curved shovel edge, higher efficiency and lower cost-in-use.
6.No resistance snail shell.
7.Adjustable output size, efficient powders production.
8.High efficiency and precision of powders collection.
9.Humanized design, easy to use.
10.Environmental protection.

Overview

MTW European Type Trapezium mill is the newest grinding equipment which enjoys many patented technology and reaches the international advanced level.

It is suitable to process non-flammable and non-explosive materials with moisture less than 6% and Mohs’ hardness less than 9 such as calcite, chalk, limestone, dolomite, kaolin, bentonite, talcum, talc, magnetite, iolite, vermiculite, barite, gypsum earth, fluorite, etc.

Working Principle

First, raw material should be crushed by the jaw crusher to the size specified, and then the crushed stuff is elevated into a hopper from which the stuff is loaded, through the vibrating feeder, evenly and continuously into the grinding chamber for power-processing. After this, the ground stuff is carried by the air into the separator for screening. The fine powder are blow into the cyclone collector and are poured out through the output-powder valve as the final products and the rough stuff after the screening will be recycled back into the grinding chamber for regrinding. The set's airflow system is closely sealed up and circulated under condition of negative pressure.

Specifications

Table 1

Model Specification Name	MTW110	MTW138	MTW175	MTW215
Quantity of roller (PCS)	4	4	5	5
Inner diameter of ring (mm)	Ф1100	Ф1380	Ф1750	Ф2150
Main shaft speed (rpm)	980	990	740	740
Max. Feeding size(mm)	30	35	40	50
Output fineness(mm)	1.6～0.045 The fineness is 0.038	1.6～0.045 The fineness is 0.038	1.6～0.045 The fineness is 0.038	1.6~0.075
Capacity(tph)	3.5～10	6.5～15	11～22	30-45
Dimension(L×W×H)(mm)	8425×5041×8642	11050×10010×10010	12850×10080×9980	14730×10860×10341
Weight(t)	18	28.5	38	92

Table 2

Model	Main mill(KW)	Classifier (KW)	Blower(KW)	Bucket elevator(KW)	Jaw crusher hammer crusher		Feeder
Model	Main mill(KW)	Classifier (KW)	Blower(KW)	Bucket elevator(KW)	Model	Power(KW)	Model	Power(W)
MTW110	55	7.5	55	3	PE250×400	15	GZ2F	0.15
MTW138	90	22	110	4	PE250×400	15	GZ3F	0.2
MTW175	160	37	200	4	PE250×750	22	GZ4F	0.45
MTW215	280	90	315	11	PC1010	110	GZ5F	0.65
