Magnetic separators have many features compact structure, no cooling system, no power excitation system, rectifying the belt automatically, simple structure, large capacity, easy to operate, easy to maintain, etc.
Overview
Magnetic separator is used for sorting magnetic minerals or removing non-magnetic minerals mixed in the magnetic minerals.
Working Principle
The material is evenly given to the magnetic field region of upper the rotating roller, magnetic substance is adsorbed on the surface of the roller and rotated together with the roller. As the non-magnetic particles and magnetic particles are suffered different magnetic force in a magnetic field,the magnetic particles are adsorbed on the surface of the roller by the magnetic field,and removed to the non-magnetic region.Non-magnetic and weakly magnetic particles are suffered by their different magnetic force.The outstripped track are different.
Specifications
CT Dry Magnetic Drum Separator Specification:
|
Model |
Roller size (Dia*length)(mm) |
Magnetic Field Strength(mT) |
Handle size (mm) |
Rotation speed of the drum r/min |
Processing capacity (t/h) |
Motor powder (kw) |
Weight (t) |
|
CT718 |
700×1800 |
250-450 |
≤20 |
30-50 |
75 |
3 |
1.8 |
|
CT722 |
700×2200 |
100 |
3 |
2 |
|
CT724 |
700×2400 |
125 |
4 |
2.2 |
|
CT726 |
700×2600 |
135 |
4 |
2.4 |
|
CT818 |
800×1800 |
100 |
4 |
2.1 |
|
CT822 |
800×2200 |
140 |
4 |
2.4 |
|
CT824 |
800×2400 |
180 |
5.5 |
2.6 |
|
CT826 |
800×2600
|
220 |
5.5 |
2.8 |
|
CT918 |
900×1800 |
150 |
4 |
2.4 |
|
CT922 |
900×2200 |
200 |
4 |
2.8 |
|
CT924 |
900×2400 |
250 |
5.5 |
3.1 |
|
CT926 |
900×2600 |
300 |
5.5 |
3.3 |
|
CT1015 |
970×1500 |
200 |
5.5 |
2.5 |
|
CT1018 |
970×1800 |
260 |
5.5 |
3 |
|
CT1022 |
970×2200 |
320 |
7.5 |
3.5 |
|
CT1024 |
970×2400 |
350 |
7.5 |
4 |
|
CT1026 |
970×2600 |
410 |
7.5 |
4.25 |
CTB Wet Magnetic Drum Separator Specification:
|
Model |
Drum data |
Magnetic induction intensity of drum surface mT |
Handling Capacity |
Motor power kw |
Rotation speed r/min |
Weight kg |
|
Dia mm |
L mm |
t/h |
m³/h |
|
CTB-618 |
600 |
1800 |
Depends on material character (60-550mT) |
15-30 |
40-80 |
2.2 |
40 |
1340 |
|
CTB-718 |
750 |
1800 |
20-45 |
60-100 |
3 |
35 |
2100 |
|
CTB-918 |
900 |
1800 |
25-40 |
70-120 |
4 |
28 |
2900 |
|
CTB-1018 |
1050 |
1800 |
45-60 |
110-160 |
5.5 |
22 |
4000 |
|
CTB-1021 |
1050 |
2100 |
50-70 |
140-200 |
5.5 |
22 |
4500 |
|
CTB-1024 |
1050 |
2400 |
60-80 |
170-260 |
5.5 |
22 |
5000 |
|
CTB-1030 |
1050 |
3000 |
80-120 |
240-380 |
7.5 |
22 |
6300 |
|
CTB-1218 |
1200 |
1800 |
60-75 |
160-260 |
11 |
17 |
5000 |
|
CTB-1224 |
1200 |
2400 |
80-110 |
240-330 |
11 |
17 |
5900 |
|
CTB-1230 |
1200 |
3000 |
100-140 |
260-460 |
11 |
17 |
7200 |
|
CTB-1236 |
1200 |
3600 |
120-160 |
300-550 |
15 |
17 |
8200 |
|
CTB-1240 |
1200 |
4000 |
130-170 |
330-600 |
15 |
17 |
9200 |
|
CTB-1245 |
1200 |
4500 |
150-200 |
380-660 |
15 |
17 |
11000 |
|
CTB-1530 |
1500 |
3000 |
100-180 |
290-480 |
11 |
14 |
9900 |
|
CTB-1540 |
1500 |
4000 |
150-200 |
300-540 |
15 |
14 |
12000 |
|
CTB-1545 |
1500 |
4500 |
180-240 |
400-650 |
18.5 |
14 |
15000 |
|
CTB-1550 |
1500 |
5000 |
210-280 |
500-750 |
18.5 |
14 |
18000 |
|
CTB-1824 |
1800 |
2400 |
100-140 |
260-460 |
15 |
14 |
9100 |
|
CTB-1830 |
1800 |
3000 |
140-190 |
350-560 |
18.5 |
14 |
12300 |
|
CTB-1840 |
1800 |
4000 |
200-260 |
400-650 |
30 |
14 |
18500 |
|
CTB-1850 |
1800 |
5000 |
280-320 |
550-800 |
37 |
14 |
25000 |
